Quick Specs
UN343H
Series
4K UHD
Resolution
55 "
Screen Size
Direct-Lit LED
Display Technlogy
300 x 300
VESA
2 Year
Warranty
| 65UN343H0UD | 55UN343H0UA | 50UN343H0UA | 43UN343H0UA | ||
| Category | Category | Commercial Lite | Commercial Lite | Commercial Lite | Commercial Lite |
| Design | Stand Type | 1 pole (Fixed) | 1 pole (Swivel) | 1 pole (Swivel) | 1 pole (Swivel) |
| Front Color | Dark Charcoal Gray | Dark Charcoal Gray | Dark Charcoal Gray | Dark Charcoal Gray | |
| Display | Inch | 65" | 55" | 50" | 43" |
| Resolution | 3,840 × 2,160 (UHD) | 3,840 × 2,160 (UHD) | 3,840 × 2,160 (UHD) | 3,840 × 2,160 (UHD) | |
| Video | HDR 10 Pro / HDR HLG | Yes / Yes | Yes / Yes | Yes / Yes | Yes / Yes |
| Game Optimizer | Yes | Yes | Yes | Yes | |
| Audio | Speaker (Sound Output) | 10 W + 10 W | 10 W + 10 W | 10 W + 10 W | 10 W + 10 W |
| Speaker System | 2.0 ch | 2.0 ch | 2.0 ch | 2.0 ch | |
| Broadcasting | Digital (Terrestrial / Cable) |
ATSC, Clear QAM | ATSC, Clear QAM | ATSC, Clear QAM | ATSC, Clear QAM |
| Analog | NTSC | NTSC | NTSC | NTSC | |
| Hospitality Solution |
Solution Type | Quick Menu 5.0 | Quick Menu 5.0 | Quick Menu 5.0 | Quick Menu 5.0 |
| Smart Features | Smart Home (Launcher Bar), Quick Access, HDMI-ARC (HDMI 2), Diagnostics (USB), Simplink (HDMI-CEC) (1.4), Anti-theft System (Kensington Lock, Credenza/Security Aperture (Except 65"), Lock Down Plate (Except 65")) | ||||
| Hospitality Features | Port Block, Welcome Video, Insert Image, Auto Off / Sleep Timer, Energy Saving Mode | ||||
| Connectivity | Set Side | HDMI 2.0 In (x2), Service Only (3.5 mm Stereo), USB 2.0, RS-232C (3.5 mm TRRS, Control & Service), External Speaker Out (3.5 mm Stereo) | |||
| Set Rear | HDMI 2.0 In, RF In (Tuner), AV In (3.5 mm Stereo), Digital Audio Out (Optical), ECI | ||||
| Mechanical | VESA Compatible | 300 × 300 mm | 300 × 300 mm | 200 × 200 mm | 200 × 200 mm |
| Dimensions without Stand (W × H × D) Weight without Stand |
57.2 x 35.0 x 2.3 in. 1,454 × 838 × 57.7 mm 47.4 lbs. / 21.5 kg |
48.6 x 28.1 x 2.3 in. 1,235 × 715 × 57.5 mm 30.9 lbs. / 14.0 kg |
44.1 x 25.6 x 2.2 in. 1,121 × 651 × 57.1 mm 26.7 lbs. / 12.1 kg |
38.1 x 22.2 x 2.2 in. 967 × 564 × 57.1 mm 19.4 lbs. / 8.8 kg |
|
| Dimensions with Stand (W × H × D) Weight with Stand |
57.2 x 35.8 x 13.4 in. 1,454 × 909 × 340 mm 50.5 lbs. / 22.9 kg |
48.6 x 30.6 x 11.9 in. 1,235 × 777 × 303 mm 37.9 lbs. / 17.2 kg |
44.1 x 28.1 x 11.9 in. 1,121 × 713 × 303 mm 33.7 lbs. / 15.3 kg |
38.1 x 24.5 x 11.9 in. 967 x 623 x 303 mm 26.5 lbs. / 12.0 kg |
|
| Shipping Dimensions (W × H × D) Shipping Weight |
63.0 x 38.2 x 9.0 in. 1,600 × 970 × 228 mm 63.7 lbs. / 28.9 kg |
53.5 x 33.9 x 8.1 in. 1,360 × 860 × 207 mm 49.2 lbs. / 22.3 kg |
51.9 x 31.9 x 7.4 in. 1,317 × 810 × 188 mm 41.0 lbs. / 18.6 kg |
42.3 x 26.0 x 8.0 in. 1,075 × 660 × 203 mm 34.0 lbs. / 15.4 kg |
|
| On Bezel Width (L / R / U / B) | 12.8 / 12.8 / 12.8 / 19.9 mm | 12.8 / 12.8 / 12.8 / 19.9 mm | 12.8 / 12.8 / 12.8 / 19.9 mm | 12.8 / 12.8 / 12.8 / 19.9 mm | |
| Off Bezel Width (L / R / U / B) | 6.8 / 6.8 / 6.8 / 18.4 mm | 6.9 / 6.9 / 6.9 / 18.4 mm | 7.3 / 7.3 / 7.8 / 18.4 mm | 6.9 / 6.9 / 6.9 / 18.4 mm | |
| Electrical | Power Consumption (Typ. / Max.) | 144 W / 180 W | 135 W / 163 W | 112 W / 135 W | 82 W / 119 W |
| Power Supply | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | |
| Warranty & Other | Warranty | 2 Year Limited | 2 Year Limited | 2 Year Limited | 2 Year Limited |
| Certification | FCC | FCC | FCC | FCC | |
| UPC | 1 95174 05779 7 | 1 95174 05780 3 | 1 95174 05787 2 | 1 95174 05812 1 | |
The UN343H Series
Features
FAQ
We carry all makes and models of Hospitality Televisions on the market. If you don't see it on the storefront, it likely was discontinued.
- To find which new model has replaced it, enter your model into the "Search Bar" on our website.
- To check if we have any backstock in our warehouse, call us at (866) 469-7111 or Request a Quote!
Consumer-grade televisions are great for your living room, but often fall short in hospitality guest rooms. Here's why:
- Warranty - Commercial TVs come standard with a robust, 2-year warranty with option to purchase extended coverage. Consumer TVs have a 90 day limited warranty.
- Technology - Hospitality TVs are equipped with Digital Rights Management (DRM) that protects HD programming from illegal duplication. DRM is required to deliver HD content to your guests.
- Security and Maintenance - Hospitality TVs contain features that allow management to control access from one centralized location.
Learn More about Hospitality vs Consumer TVs
Hotel Brand Standards, budget, features (SMART, Pro:Idiom, b-LAN), and current promotions are all factors to consider when making an investment in Hospitality Televisions.
Discuss your options with one of our experienced Project Managers today: (866) 469-7111.
- VIP Pricing: Our volume grants us access to the best manufacturer pricing in the industry.
- Service: We offer free, unbiased project consultation and a dedicated, experienced project manager.
- Extras: We adapt to your project needs - KniTec can handle your warranty claims, installation, and content creation.
Learn More about the KniTec Difference
Call us at (866) 469-7111 or email us at sales@knitec.com.
