Model Specifications
4K UHD
Resolution
65"
Screen Size
OLED
Display Technlogy
12/7
Run Time
770 nit
Brightness
3 Year
Warranty
| Tech Spec | |
| Panel | |
| Screen Size | 65" |
| Panel Technology | OLED |
| Native Resolution | 3,840 X 2,160 (UHD) |
| Brightness | 950 / 850 / 450 / 175 @D65 (APL 3% / 10% / 25% / 100%) |
| Contrast Ratio | 1,850,000 : 1 |
| Color gamut | DCI-P3 98.5% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 1.07 Billion Colors (10 bit) |
| Operation Hours (Hours / Days) | 12 / 7 (Moving Content Only) |
| Portrait / Landscape | No / Yes |
| Mechanical Specification | |
| Bezel Color | Black |
| Bezel Width | Off Bezel : 2.0 / 2.0 / 2.0 / 2.0 mm (T/R/L/B) |
|
On Bezel : 8.7 / 8.9 / 8.9 / 11.6 mm (T/R/L/B)
|
|
| Weight (Head) | 31 kg |
| Weight (Head+Stand) | 35 kg |
| Packed Weight | 45.5 kg |
| Monitor Dimensions (W × H × D) | 1,446.3 × 853.8 × 56.5 mm (w/ Control Box) |
| Monitor Dimensions with Stand (W × H × D) | 1,446.3 × 896.5 × 272 mm |
| Carton Dimensions (W × H × D) | 1,670 × 200 × 1,108 mm (Box Outer Size) |
| Handle | Yes |
| VESA™ Standard Mount Interface | 300 × 300 mm |
| Key Feature | |
| SW | webOS 5.0, Multi-screen (PIP, PBP (2)) |
| Picture | Color Adjustment (OLED Light, Contrast, Chroma, Sharpness, Tint), Color Temp (VAR / 9300 K / 6500 K / 5400 K / 3200 K / D65 (6504 K) / C (6774 K) / D-Cinema (6302 K)), Over Scan (Zero Scan, Over Scan, Under Scan), Aspect Ratio (Full Wide, 4:3, 14:9, 13:9, 1.85:1, 2.35:1, 1:1, Original), AFD (Active Format Description) (Yes), Zoom (×2 ~ ×5), HDR / SDR Monitoring (Yes), 3rd Party Cal. SW Compatibility (CalMAN - Including Uniformity Compensation, 9 p / 13 p / 25 p, EBU Grade1) (LG Connect must be on.), Eyesafe Certification (Less than 50% of Blue Light Emission) (Yes), Color Accuracy : DeltaE < 2 (Yes) |
| Color | Gamut (Native, P3, BT.709, SMPTE-C, BT.2020, EBU, Adobe RGB, NTSC), SDI Color Format (Auto, RGB444, YCbCr444, YCbCr422), R/G/B Gain (-768 ~ 255), Mono/Blue Only, Transfer Matrix, Mastering Peak, EOTF (Auto / User / 1.9 / 2.2 / 2.4 / 2.6 / SDR (Calibration) / ST.2084 PQ / BT.2100 HLG / HDR (Calibration) / Dolby Vision / Dolby Vision (Calibration)) |
| Marker | Marker, Safety Area, Center Marker |
| Audio | Audio Level Meter (Ch1~16, Selectable), Dolby Atmos (2Ch, Down Mix through Audio Out Port) |
| GPI | GPI Control (General Purpose Interface) |
| Video Analysis | Waveform, Vector Scope, Time Code (LTC, VITC), PIP/PBP |
| Advanced | Profile Load / Save (Profile 1~10), Function Key (Function1~5), Tally, Gen Lock, LG Connect, 3rd Party Control Pad Compatibility (Open API), Remote IP Control App (HTML) |
| Environment Conditions | |
| Operation Temperature | 0 °C to 40 °C |
| Operation Humidity | 10 % to 80 % |
| Power | |
| Power Supply | AC 100-240V~, 50/60Hz |
| Power Consumption | |
| Typ./Max. | 300 W / 470 W |
| BTU (British Thermal Unit) | 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.) |
| Certification | |
| Safety | CB / NRTL |
| EMC | FCC Class "A" / CE / KC |
| ErP | Yes (EU Only) |
| Software Compatibility | |
| SuperSign WB | Yes |
| CalMAN SW Compatibility | Yes |
| IP Remote Utility | Yes |
| Connectivity | |
| Input | HDMI (2, (HDCP1.4/2.2, HDMI2.1)), SDI (4, 12G × 4, Single Link : SD / HD / 3G / 6G / 12G, Dual Link : HD / 3G_4K , Quad Link : HD_4K / 3G_4K, Quad View : SD / HD / 3G / 6G / 12G), REF (Black Burst, Tri-Level), USB 2.0 Type A (SW update, & Calibration), Power (AC) |
| Output | Audio (Head-Phone), SDI (4, Loop-through) |
| External Control | RS-232C In (Service Only), RJ45 (LAN, 100base-T) In, RJ45 (Remote, GPI 7port) In / Out, SFP In (SFP+, Support Only for The Embrionix's SFP Module), IR In |
| Accessory | |
| Basic | Remote Controller, IG (Installation Guide), Regulation Book |
The EP5G-B Series
Key Features
FAQ
- Quality and Performance: Professional displays are typically built to higher standards with superior image quality and performance. They often feature advanced technologies like high color accuracy, wider color gamut, deeper black levels, and better image processing capabilities.
- Durability and Reliability: Professional displays are engineered to withstand continuous and demanding use in commercial environments. They are built with higher-quality components, have better heat management systems, and are designed to operate for extended hours without compromising performance or longevity.
- Connectivity and Customization: Professional displays often offer a wider range of input and output options to accommodate various professional devices and workflows. They may include specialized ports for connecting professional-grade cameras, video editing equipment, and other peripherals.
