Model Specifications
4K UHD
Resolution
86"
Screen Size
IPS
Display Technlogy
16/7
Run Time
350 nit
Brightness
3 Year
Warranty
| PANEL | MODEL | 86TR3DJ | 75TR3DJ | 65TR3DJ | |
| Screen Size | 86" | 75" | 65" | ||
| Panel Technology | IPS | IPS | IPS | ||
| Back Light Type | Direct | Direct | Direct | ||
| Aspect Ratio | 16:9 | 16:9 | 16:9 | ||
| Native Resolution | 3840 x 2160 (UHD) | 3840 x 2160 (UHD) | 3840 x 2160 (UHD) | ||
| Refresh Rate | 60Hz | 60Hz | 60Hz | ||
| Brightness (Typ) | 350 nits | 350 nits | 350 nits | ||
| Contrast Ratio | 1200:1 | 1200:1 | 1200:1 | ||
| Color gamut | NTSC 68% | NTSC 68% | NTSC 68% | ||
| Viewing Angle (H x V) | 178° X 178° | 178° X 178° | 178° X 178° | ||
| Color Depth | 10bit, 1.07Billion colors | 10bit, 1.07Billion colors | 10bit, 1.07Billion colors | ||
| Response Time | 8ms (G to G) | 8ms (G to G) | 8ms (G to G) | ||
| Surface Treatment(Haze) | Anti Glare, 7H(Mohs) | Anti Glare, 7H(Mohs) | Anti Glare, 7H(Mohs) | ||
| Lifetime Operation | 30,000 Hrs | 30,000 Hrs | 30,000 Hrs | ||
|
Operation Hours (Hours/Day) |
16/7 | 16/7 | 16/7 | ||
| Portrait / Landscape | Landscape Only | Landscape Only | Landscape Only | ||
| TOUCH | Available object size for touch | ≥3 mm | ≥3 mm | ≥3 mm | |
| Reponse Time | ≤60 ms (Android) ≤100 ms (Windows) |
≤60 ms (Android) ≤100 ms (Windows) |
≤60 ms (Android) ≤100 ms (Windows) |
||
| Accuracy | ±2 mm | ±2 mm | ±2 mm | ||
| Interface | USB 2.0 | USB 2.0 | USB 2.0 | ||
| Protection Glass Thickness | 4T (Anti-Glare) | 4T (Anti-Glare) | 4T (Anti-Glare) | ||
| Protection Glass Trans- mission | 87% | 87% | 87% | ||
| Operating System Support | Windows XP/7/8/10, Linux, Mac, Android (WindowsXP/Linux/Mac support one point touch) | Windows XP/7/8/10, Linux, Mac, Android (WindowsXP/Linux/Mac support one point touch) | Windows XP/7/8/10, Linux, Mac, Android (WindowsXP/Linux/Mac support one point touch) | ||
| Multi touch point | Max 20 Points | Max 20 Points | Max 20 Points | ||
| SOUND | Built-in Speakers | 10W x 2 | 10W x 2 | 10W x 2 | |
| CONNECTIVITY | HDMI In | Yes (3), HDCP2.2/1.4 | Yes (3), HDCP2.2/1.4 | Yes (3), HDCP2.2/1.4 | |
| Analog RGB In | Yes (1) | Yes (1) | Yes (1) | ||
| Audio In | Yes (1) | Yes (1) | Yes (1) | ||
| RS232C In | Yes (1) | Yes (1) | Yes (1) | ||
| RJ45 (LAN) | Yes (1) | Yes (1) | Yes (1) | ||
| USB In | USB3.0 Type A(3) USB2.0 Type A(3) | USB3.0 Type A(3) USB2.0 Type A(3) | USB3.0 Type A(3) USB2.0 Type A(3) | ||
| Audio Out | Optical (1) | Optical (1) | Optical (1) | ||
| Touch USB Out | Yes (2) | Yes (2) | Yes (2) | ||
| MECHANICAL | Bezel Color | Black | Black | Black | |
| Bezel Width | 18.9 / 18.9 / 18.9 / 45.7 mm | 18.9 / 18.9 / 18.9 / 45.7 mm | 18.9 / 18.9 / 18.9 / 45.7 mm | ||
| Weight | 148.7 lbs / 67.5 kg | 117.1 lbs / 53.1 kg | 85.4 lbs / 38.8 kg | ||
| Shipping Weight | 190.9 lbs / 86.6 kg | 154.0 lbs / 69.9 kg | 106.9 lbs / 48.5 kg | ||
|
Monitor Dimension (W x H x D) |
77.0 x 45.7 x 3.4 in 1957 × 1160 × 87 mm |
67.3 x 40.2 x 3.4 in 1710 × 1020 × 87 mm |
58.6 x 35.3 x 3.4 in 1489 × 897 × 87 mm |
||
|
Carton Dimensions (W x H x D) (Box outer size) |
83.1 x 50.5 x 11.0 in 2112 × 1283 × 280 mm |
73.2 x 44.9 x 11.0 in 1860 × 1140 × 280 mm |
64.1 x 39.6 x 8.2 in 1628 × 1005 × 208 mm |
||
| Handle | Yes | Yes | Yes | ||
| Stand | No | No | No | ||
|
VESATM Standard Mount Interface |
800 x 600mm | 800 x 400mm | 600 x 400mm | ||
| Operation Temperature | 32° to 104° F / 0° to 40° C | 32° to 104° F / 0° to 40° C | 32° to 104° F / 0° to 40° C | ||
| Operation Humidity | 10% to 80% | 10% to 80% | 10% to 80% | ||
| OPS type compatible | Yes (Slot) | Yes (Slot) | Yes (Slot) | ||
| OPS Power built in | Yes | Yes | Yes | ||
| FEATURES | Internal Memory | 16 GB | 16 GB | 16 GB | |
| Built-in Wi-Fi | Yes (Removable) | Yes | Yes | ||
| Power Indicator | Yes | Yes | Yes | ||
| Local Key Operation | Yes | Yes | Yes | ||
| Fanless Design | Yes | Yes | Yes | ||
| Android Version | Android 8.0 | Android 8.0 | Android 8.0 | ||
| Screen Share | Yes (Screenshare pro) | Yes (Screenshare pro) | Yes (Screenshare pro) | ||
| POWER | Power Supply | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | |
| Power Type | Built-In Power | Built-In Power | Built-In Power | ||
| Power Consumption (Typ) | 370W | 260W | 180W | ||
| Power Consumption (Max) | 350W | 300W | |||
| Power Consumption (Off) | Less than 0.5W | Less than 0.5W | Less than 0.5W | ||
|
"WARRANTY & OTHER" |
Warranty | 3 Year Limited | 3 Year Limited | 3 Year Limited | |
| FCC (Regulatory) | Class "A" | Class "A" | Class "A" | ||
| CE (Regulatory) | Yes | Yes | Yes | ||
| ErP (Environmental) | Yes | Yes | Yes | ||
| Basic Accessories | Power Cord (3m), USB Cable (5m), HDMI Cable (3m), Writing Pen (x2), User Man- ual, Quick Start Guide, Remote Control (batteries incl.), Wi-Fi module | Power Cord (3m), USB Cable (5m), HDMI Cable (3m), Writing Pen (x2), User Man- ual, Quick Start Guide, Remote Control (batteries incl.), Wi-Fi module | Power Cord (3m), USB Cable (5m), HDMI Cable (3m), Writing Pen (x2), User Man- ual, Quick Start Guide, Remote Control (batteries incl.), Wi-Fi module | ||
The TR3DJ-B Series
Key Features
FAQ
- Quality and Performance: Professional displays are typically built to higher standards with superior image quality and performance. They often feature advanced technologies like high color accuracy, wider color gamut, deeper black levels, and better image processing capabilities.
- Durability and Reliability: Professional displays are engineered to withstand continuous and demanding use in commercial environments. They are built with higher-quality components, have better heat management systems, and are designed to operate for extended hours without compromising performance or longevity.
- Connectivity and Customization: Professional displays often offer a wider range of input and output options to accommodate various professional devices and workflows. They may include specialized ports for connecting professional-grade cameras, video editing equipment, and other peripherals.
