Samsung UE46C Model Specifications (Discontinued)
1080p FHD
Resolution
46"
Screen Size
E-LED BLU
Display Technology
500 nit
Brightness
3 Year
Warranty
Run Time
| Diagonal Size | 46″ |
| Type | 240Hz e-LED BLU |
| Resolution | 1920 x 1080 (16:9) |
| Pixel Pitch(mm) | 0.15375 (H) x 0.46125 (V) |
| Active Display Area | 1018.08 (H) x 572.67 (V) |
| Brightness (Typical) | 500nit |
| Contrast Ratio (Dynamic) | 100000:1 |
| Viewing Angle (H/V) | 178° / 178° |
| Response Time (G-to-G) | 4ms |
| Display Colour | 10bit Dithering – 1.07Billion |
| Colour Gamut | 72% |
| Contrast Ratio | 5000:1 |
| Input | RGB |
| Analog D-SUB, DVI-D, Display Port 1.2 | |
| Video | |
| HDMI1, HDMI2, Component (CVBS Common) | |
| Audio | |
| Stereo mini Jack | |
| Output | RGB |
| DP1.2 (Loop-out) | |
| Audio | |
| Stereo mini Jack | |
| External Control | RS232C (in / out) thru stereo jack, RJ45 |
| External Sensor | IR, Ambient Light |
| Dimension | Set Dimension (WxHxD) |
| 1030.3 x 584.8 x 29.9mm | |
| Package Dimension (WxHxD) | |
| 1170.0 x 705.0 x 199.0mm | |
| Weight | Set Weight |
| 11.6kg | |
| Package Weight | |
| 15.5kg | |
| Bezel Width(mm) | 5.5mm |
| VESA Mount | 400 x 400mm |
| Stand Type | Foot Stand (Optional) |
| Media Player Option Type | Embbeded, SBB-C (Attachable) |
| Operating Temperature | 0°C ~ 40°C |
| Humidity | 10 ~ 80% |
| Special | ACM Support (Advanced Colour Management), Magic Clone (to USB), Auto Source Switching & Recovery, Lamp Error Detection, Super Clear Coating, Temperature Sensor, RS232C / RJ45 MDC, Plug and Play (DDC2B), PIP / PBP, Video Wall (10 x 10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain (Supporting 2 x 2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F / W update, Clock Battery (80hrs Clock Keeping), Built in Speaker |
| Built In MagicInfo (Lite, Premium-S, Videowall-S) | |
| Internal Player (Embedded H/W) | Processor |
| Cortex-A9 1GHz Dual Core CPU | |
| On-Chip Cache Memory | |
| L1 (I / D): 32KB / 32KB | |
| L2 (Unified): 512KB | |
| Clock Speed | |
| 1GHz CPU Dual | |
| Main Memory Interface | |
| 1GB Dual 32bit DDR3-667 (1333MHz) | |
| Graphics | |
| 2D & 3D Graphics Engine | |
| – Up to 1920 x 1080. 32bpp | |
| – Supports OpenGL ES | |
| Storage (FDM) | |
| 8GB (2GB Occupied by O / S, 6GB Available) | |
| Multimedia | |
| Video Decoder | |
| – MPEG – 1/2, H.264 / AVC (Dual) | |
| – VC-1, JPEG, PNG Audio DSP (Decoder) | |
| – AC3 (DD), MPEG, DTS and etc. | |
| IO Ports | |
| USB 2.0 | |
| Operating System | |
| Linux | |
| Power Supply | AC 100 – 240V ~ (+ / – 10%), 50 / 60Hz |
| Power Consumption | Off Mode |
| less than 0.5W | |
| On Mode | |
| 132 (Max) / 89 (Typ.) / 450.12 (BTU) | |
| Sleep Mode | |
| less than 0.5W | |
| CPU | SBB-C (optional) |
| N/B | SBB-C (optional) |
| S/B | SBB-C (optional) |
| Embedded OS | SBB-C (optional) |
| GPU | SBB-C (optional) |
| FDM/HDD | SBB-C (optional) |
| Memory | SBB-C (optional) |
| Ethernet | SBB-C (optional) |
| Connectivity | USB |
| SBB-C (optional) | |
| Output | |
| SBB-C (optional) | |
| Others | |
| SBB-C (optional) | |
| Safety | CUL (USA + Canada): UL60065 |
| TUV (Germany): EN60065 | |
| CB (Europe): IEC60065 / EN60065 | |
| EK (Korea): K60065 | |
| CCC (China): GB8898 | |
| PSB (Singapore): IEC60065 | |
| GOST (Russia): IEC60065, EN55022 | |
| SIQ (Slovenia): IEC60065, EN55022 | |
| PCBC (Poland): IEC60065, EN55022 | |
| NOM (Mexico): NOM-001-SCFI-1993 | |
| IRAM (Argentina): IRAM | |
| SASO (Saudi Arabia): IEC60065 | |
| EMC |
The UE46C Series
