DISPLAY |
|
DIAGONAL SIZE |
75” 65″ 55″ 49″ |
TYPE |
Nanocell (Nano Bezel) Backlight Edge |
RESOLUTION |
3,840 x 2,160 (UHD) |
BRIGHTNESS |
400 nits |
|
|
BROADCAST SYSTEM |
|
TV RECEPTION |
ATSC / Clear QAM/VSB, Analog NTSC |
|
|
VIDEO |
|
HDR (DOLBY VISION / 10 PRO / HLG) |
75″ – Yes / Yes / Yes 65″ – No / Yes / Yes 55″- No / Yes / Yes 49″- No / Yes / Yes |
|
|
AUDIO |
|
AUDIO OUTPUT / SPEAKER SYSTEM |
75″ – 20W + 20W / 2.0ch 65″ – 10W + 10W / 2.0ch 55″ – 10W + 10W / 2.0ch 49″ – 10W + 10W / 2.0ch |
DOLBY ATMOS |
Yes |
ONE TOUCH SOUND TUNING |
Ready |
|
|
HOSPITALITY FEATURES |
|
YES |
Hotel Mode(Installer Menu), Welcome Screen(Splash Image), Insert Image, One Channel Map(LCM), External Speaker Out (Int / Ext Variable / Fixed), Instant ON, V-Lan Tag, RJP (Remote Jack Pack) Compatibility, Auto Off / Sleep Timer, Motion Eye Care |
|
|
HOSPITALITY SOLUTION |
|
SOLUTION TYPE |
Pro:Centric (Smart, V, Direct), Quick Menu 3.0 |
DATA STREAMING ( IP & RF ) |
Yes |
HCAP (GEM / FLASH / HTML) SERVICE CAROUSEL (TLL / XML) |
GEM / HTML5 |
IP RETURN PATH |
Yes |
MULTICAST / UNICAST READY |
Yes / Yes |
WEBRTC (REAL TIME COMMUNICATION) |
Yes |
PRO: CENTRIC APPLICATION (VERSION) |
PCA3.8 |
PRO: CENTRIC SERVER |
PCS400R |
DRM |
Pro:Idiom (S/W Type), Pro:Idiom Media |
|
|
SMART FEATURE |
|
|
webOS 4.5, Smart Home (Launcher Bar), Quick Access, Web Browser, Pre-loaded App, SDP Server compatibility, Magic Remote Compatibility (Ready), Clock (World Clock / Alarm), Soft AP, Wi-Fi (802.11ac, Built-in type), Screen Share (Miracast), Smart Share (DLNA), LG TV Plus App Compatibility, DIAL, Bluetooth Audio Playback, LG Sound Sync / Bluetooth, Mobile Connection Overlay, Voice Recognition (Standalone / Solution), IoT, EzManager (Simplicity), USB Cloning, Wake on RF, Wake on LAN, SNMP, Diagnostics (IP Remote), SI Compatible (TVLink Interactive, MPI, RS232C), HTNG-CEC (1.4), Simplink (HDMI-CEC, 1.4), IR Out (RS-232C, HDMI), Multi IR Code, Anti-theft System (Kensington Lock), Chromecast Dongle Anti-theft Cover (Optional) |
|
|
HOSPITALITY FEATURE |
|
|
Hotel Mode(Installer Menu), Welcome Screen(Splash Image), Insert Image, One Channel Map(LCM), External Speaker Out (Int / Ext Variable / Fixed), Instant ON, V-Lan Tag, RJP (Remote Jack Pack) Compatibility, Auto Off / Sleep Timer, Motion Eye Care |
|
|
JACK INTERFACE |
|
SET SIDE |
HDMI In 2.0(2), USB 2.0 |
SET REAR |
75″ – RS-232C (Control & Service, Phone Jack Type) RJ45 (Usage Purpose : 1 (Ethernet)) 65″ – HDMI In (HDCP, 2.0), AV In (Phone Jack Type), RS-232C (Control & Service), RJ45 (Usage Purpose : 2 (Ethernet, Aux)) 55″ – HDMI In (HDCP, 2.0), AV In (Phone Jack Type), RS-232C (Control & Service), RJ45 (Usage Purpose : 2 (Ethernet, Aux)) 49″ – HDMI In (HDCP, 2.0), AV In (Phone Jack Type), RS-232C (Control & Service), RJ45 (Usage Purpose : 2 (Ethernet, Aux))
RF In(Dual b-Lan), Digital Audio Out (Optical), External Speaker Out (3.5mm Phone Jack) : 1 (Spk-out fixed 0.01W~1.00W and line out), TV link Configuration(phone jack type) : 1 (b-LAN Service), MPI Port(RJ12 jack), Debug (Phone Jack Type) : 1(CPU/PTC)
|
|
|
DIMENSION |
|
VESA |
75″ – 600 x 400 65″ – 300 x 300 55″ – 300 x 300 49″ – 200 x 200 |
W X H X D / WEIGHT (WITH STAND) |
75″ – 1,683 x 1,043 x 369.8 / 41.6 65″ – 1,451 x 910 x 323.7 / 25.8 55″ – 1,232 x 773 x 303 / 20.4 49″ – 1,096 x 697 x 303 / 17.2 |
W X H X D / WEIGHT (WITHOUT STAND) |
75″ – 1,683 x 974 x 35.1(65.2) / 38.8 65″ – 1,451 x 840 x 64 / 24.1 55″ – 1,232 x 716 x 63.6 / 17.2 49″ – 1,096 x 640 x 63.6 / 14.0 |
W X H X D / WEIGHT (SHIPPING) |
75″ – 1,839 x 1,166 x 231 / 52.2 65″ – 1,600 x 1,035 x 207 / 33.3 55″ – 1,360 x 860 x 207 / 25.6 49″ – 1,192 x 760 x 190 / 20.0 |
|
|
POWER (UNIT : WATTS) |
|
POWER SUPPLY (VOLTAGE, HZ) |
AC 120 V ~ 50 / 60 Hz |
TYPICAL |
75″ – 183.3W 65″ – 169W 55″ – 140W 49″ – 126W |
STAND-BY |
Under 0.5W |
