DISPLAY |
|
DIAGONAL SIZE |
43” class (42.5″ diag) |
TYPE |
Edge LED |
RESOLUTION |
3,840 x 2,160 (4K UHD) |
DYNAMIC CONTRAST RATIO |
1,000,000:1 |
STATIC (PANEL) CONTRAST RATIO |
1,200:1 |
VIEWING ANGLE DEGREE |
178°/178° |
RESPONSE TIME (G TO G) |
8 |
FRAME RATE |
T120 |
|
|
BROADCAST SYSTEM |
|
DIGITAL |
ATSC / VSB / Clear QAM |
ANALOG |
NTSC |
MPEG-2 / MPEG-4 H.264 DECODING |
Yes |
|
|
VIDEO |
|
TRIPLE XD ENGINE |
Yes |
REAL CINEMA 24P (3:3 PULL DOWN) |
Yes |
PICTURE MODE |
10 modes (Vivid, Standard, Eco, Cinema, Sports, Game, Photo, HDR Effect, Expert (Bright Room), Expert (Dark Room)) |
ASPECT RATIO |
6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan) |
HDR |
Dolby VisionTM HDR, HDR10 |
|
|
AUDIO |
|
AUDIO OUTPUT / SPEAKER SYSTEM |
10W + 10W / 2.0ch |
SOUND MODE |
Yes 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game) |
CLEAR VOICE |
Yes |
|
|
GENERAL FEATURES |
|
MANAGEMENT |
Wake on RF, WOL (Wake on LAN) SNMP, Remote Diagnostics, MPI Protocol, IR Out, Multi IR Code, HTNG/HDMI-CEC |
INTERACTIVITY |
HTNG / HDMI-CEC |
INSTALLATION |
EzManager, USB Cloning |
RJP COMPATIBILITY |
Yes |
USB MEDIA |
Moving Picture Playback (.asf, .wmv, .avi, .mp4, .m4v, .mov, .3gp, .3g2, .mkv, .mpg, .mpeg, .dat, .etc), Picture (jpeg, jpg, jpe, BMP, PMG) Audio Codec (.mp3, .way, .OGG, .WMA, .fl ac) |
ADVANCED SETTING OPTION |
AUTO OFF/SLEEP TIMER, SMART ENERGY SAVING, MOTION EYE CARE |
ANTI-THEFT SYSTEM |
Kensington Lock, Credenza/Security Screw Hole, Lock Down Plate |
|
|
HOSPITALITY FEATURES |
|
YES |
PDM(Installer menu), Welcome Screen(Splash Image), Insert Image(webOS default), Logical Channel Map, External Speaker Out, Instant ON, RJP Compatibility, b-LANTM embedded |
|
|
INTERFACE |
|
SIDE |
HDMI In, USB 2.0 |
REAR |
RF In (b-LAN), AV In, Digital Optical Audio Out, HDMI Input, USB, RS-232C, RJ45(2), External Speaker Out, TV Link Configuration (b-LAN Service), MPI Port, Debug |
|
|
DESIGN |
|
STAND |
(±20/45/90°) Swivel |
|
|
ACCESSORIES |
|
YES |
Power Cable (5.9 ft.), Owner’s Manual / Easy Setup Guide |
|
|
DIMENSIONS |
|
VESA (MM) |
200 x 200 |
WXHXD / WEIGHT (WITHOUT STAND) |
38.1″ x 22.3″ x 2.4″ / 22.5lb |
WXHXD / WEIGHT (WITH STAND) |
38.1″ x 24.3″ x 11.9″ / 29.5lb |
WXHXD / WEIGHT (CARTON) |
46.5″ x 26.0″ x 7.5″ / 34.0lb |
|
|
POWER |
|
VOLTAGE, HZ |
100 ~ 240V, 50/60Hz |
TYPICAL (WATTS) |
51.4 |
STAND-BY (WATTS) |
Less Than 0.5 |
|
|
STANDARD APPROVAL |
|
SAFETY |
UL |
ENVIRONMENT |
FCC |
ETC. |
RoHS, UL, ENERGY STAR® Qualified, Dolby VisionTM |
|
|
UPC |
719192611573 |
|
|
SOLUTION |
|
TYPE |
Pro:Centric® SMART / Pro:Centric® Direct |
DATA STREAMING (IP&RF) |
Yes |
PRO:CENTRIC APPLICATION |
Yes |
RF |
2 Tuner |
HCAP (SDK) |
GEM / Flash / HTML |
IP RETURN PATH |
Yes |
SERVER |
PCS400S, PCS200S |
DIGITAL RIGHTS MANAGEMENT |
Pro:Idiom |
|
|
SMART FEATURES |
|
SMART UX |
webOS 3.5, Commercial Smart Home, Web Browser, Pre-loaded Apps, SDP (Software Defined Perimeter), Magic Remote (Optional) |
CONNECTIVITY |
SoftAP, WiFi (802.11a/b/g/n/ac), ScreenShare (Miracst), SmartShare, DIAL, Bleutooth Sound Sync, LG Sound Sync |
