DISPLAY |
|
|
|
Backlight LED |
Screen Size (Inch) 40″ |
Resolution 1920 X 1080 |
HD / FHD FHD |
VIDEO |
|
|
|
Picture Engine HyperReal |
Static Contrast Ratio 5000:1 |
Viewing angle (H/V) 178/178 |
Dynamic Contrast Ratio Mega Contrast |
Micro Dimming N/A |
Response Time 8ms |
Wide Color Enhancer (Plus) Yes |
Film Mode Yes |
AUDIO |
|
|
|
Dolby Dolby MS10 |
Auto Volume Leveler Yes |
DTS Studio Sound / DNSe+ DTS Studio Sound |
Speaker Type Down Firing + Full Range |
DTS Premium Sound / DTS Premium Sound 5.1 DTS Premium Sound 5.1 |
Sound Output (RMS) Dolby MS10 |
Woofer N/A |
3D Sound N/A
Variable Speaker Output N/A
|
FEATURE |
|
|
|
Mobile to TV – Mirroring, DLNA Yes |
360 Video Player N/A |
Together play N/A |
Easy Setup N/A |
App Casting Yes |
Bluetooth Low Energy N/A |
WiFi Direct N/A |
|
LOCALIZATION |
|
|
|
Sports Mode N/A |
All Care Protection N/A |
|
|
SYSTEM |
|
|
|
Digital Broadcasting ASTC/Clear QAM |
Analog Tuner Yes |
CI (Common Interface) N/A |
Data Broadcasting N/A |
FEATURE |
|
|
|
Smart Hub Yes |
TV SoundConnect No |
Apps Yes |
OSD Language English, Spanish, French |
Web Browser Yes |
Digital Clean View Yes |
Samsung SMART View Yes |
HDMI 3D Auto Setting No |
Voice Control N/A |
HDMI 1.4 A / Return Ch. Support (ARC) Yes |
Samsung 3D N/A |
Anynet+ (HDMI-CEC) No |
3D Converter N/A |
BD Wise Plus No |
Wireless LAN Built-in Yes |
Auto Channel Search Yes |
AllShare – Contents Sharing Yes |
Auto Power Off Yes |
AllShare – Screen Mirroring Yes |
EPG Yes |
ConnectShare™(USB 2.0) Yes |
Teletext (TTX) N/A |
Wake On LAN Yes |
Caption (Subtitle) Yes |
Wake On WiFi N/A |
Wake-up Timer Yes |
Soft AP Yes |
Sports Mode 2.0 No |
HOSPITALITY FEATURE |
|
|
|
Samsung LYNK™ HMS Compatibility Yes |
H.Browser Compatibility Yes |
Samsung LYNK™REACH (IP) REACH 4.0 |
Samsung LYNK™REACH (RF) REACH 4.0 |
Hospitality Home Menu Yes |
Music Mode BackLight on/off Yes |
Samsung LYNK™REACH Yes |
Auto Source Mode Yes |
Samsung LYNK™REACH Server Compatibility Yes |
Energy Saving Mode(BLU control) Yes |
External Clock Compatibility N/A |
Samsung LYNK™SINC Compatibility Yes |
Clock Back Up Supply Yes |
External Clock Back Up Supply N/A |
H.Browser Compatibility Yes |
External Clock Dimming Control N/A |
Hospitality Plug&Play (Easy Set-up) Yes |
Software Clock Yes |
My Channel N/A |
RJ 12 / IR Pass Through Yes |
Multi Code Remote Control Yes |
Power on Mode Yes |
Screwed Remote Battery Cover No |
USB Cloning Yes |
Security Mode No |
Hotel Channel List N/A |
On/Off Timer (Schedule) N/A |
Mixed Channel List N/A |
Smoovie Compatibility Yes |
Sound bar compatibility No |
Logo Display with Time Out Setting (BMP/Movie) Yes |
Samsung LYNK™DRM Yes |
Pro:Idiom Yes |
Welcome Message Yes |
bLAN No |
Music Mode (Input : PC/AV/Component/HDMI) Yes |
INPUT & OUTPUT |
|
|
|
HDMI (Side/Rear) 2/2 |
RF In (Terrestrial/Cable input) (Side/Rear) 1/0 |
USB (Side/Rear) 1/0 |
RF In (Satellite input) (Side/Rear) N/A |
Component In (Y/Pb/Pr) (Side/Rear) 0/1 |
RS232C Yes (Common Use with RJP as EX-LINK) |
Pillow Speaker Jack (Side/Rear) 0/1 |
Composite In (AV) (Side/Rear) 0/1 (Common Use for Component Y) |
CI Slot (Side/Rear) N/A |
Ethernet (LAN) (Side/Rear) 1/0 |
Variable Audio Out (Side/Rear) No |
Headphone (Side/Rear) No |
Variable Audio Out Volume Control (Side/Rear) No |
Headphone ID (Side/Rear) No |
Digital Audio Out (Optical) (Side/Rear) 0/1 |
RJ12 for External Control (Side/Rear) 0/1 |
Audio Out (Mini Jack) (Side/Rear) 0/1 |
RJP Jack (Remote Jack Pack) (Side/Rear) 0/1 |
PC In (D-sub) (Side/Rear) N/A |
PC/DVI Audio In (Mini Jack)(Side/Rear) 0/1 |
Video Out (Side/Rear) N/A |
Door-Eye (Side/Rear) N/A |
Scart (Side/Rear) N/A |
Door-Eye Video In (Side/Rear) N/A |
DESIGN |
|
|
|
Front Color Black |
Swivel (Left/Right) N/A |
Stand Type N/A |
|
ECO |
|
|
|
Energy Efficiency Class N/A |
Eco Sensor Yes |
|
|
POWER |
|
|
|
Power Consumption (Energy Saving Mode) (Watts) N/A |
Multi Voltage AC110-220V |
Power Consumption (Rated) (Watts) 96 |
Power Consumption (IEC 62087 Edition 2) N/A |
Power Consumption (Stand-by) (Watts)0.9 |
Peak Luminance Ratio N/A |
Yearly Power Consumption (EU standard,kWh) N/A |
Power Consumption (Typical) (Watts) 32 |
DIMENSION |
|
|
|
Set Dimension with Stand (WxHxD) (mm) N/A |
Package Dimension (WxHxD) (mm) 1100*616*120 |
Set Dimension without Stand (WxHxD) (mm) 906.6*532.9*65.1 |
|
WEIGHT |
|
|
|
Set Weight with Stand (kg) N/A |
Package Weight (kg) 9.4 |
Set Weight without Stand (kg) 7.8 |
|
ACCESSORY |
|
|
|
Remote Controller Model N/A |
Power Cable Yes |
PureCare Remote(Seamless White Remote) N/A |
ANT-Cable N/A |
Battery (for Remote Control) Yes |
Data Cable No |
3D Glasses (Included) N/A |
Slim Gender Cable N/A |
Mini Wall Mount Support Yes |
Quick Install Guide Yes |
Vesa Wall Mount Support N/A |
Security Screws No |
Stand Mount Kit No |
|
|
