Model Specifications (Discontinued)
4K UHD
Resolution
85"
Screen Size
60Hz NewEdge
Display Technlogy
350 nit
Brightness
3 Year
Warranty
8/7
Run Time
Panel | Panel | ||||||
Diagonal Size | 75 | Diagonal Size | 85 | ||||
Type | New Edge, 60Hz | Type | New Edge, 60Hz | ||||
Resolution | 3840*2160 (Landscape) | Resolution | 3840*2160 (Landscape) | ||||
Brightness(Typ.) | 350 (without glass) nit | Brightness(Typ.) | 350 (without glass) nit | ||||
Contrast Ratio | 4,000:1 (without glass) | Viewing Angle(H/V) | 178:178 | ||||
Viewing Angle(H/V) | 178:178 | Response Time(G-to-G) | 6ms(Typ.) | ||||
Response Time(G-to-G) | 6ms(Typ.) | Display Colors | 16.7M | ||||
Display Colors | 16.7M | Operation Hour | N/A | ||||
Operation Hour | N/A | ||||||
Sound | Sound | ||||||
Speaker Type | Built in Speaker (10W x 2CH) | Speaker Type | Built in Speaker (10W x 2CH) | ||||
Connectivity | Connectivity | ||||||
Input | Input | ||||||
Video | HDMI 2(Rear 1, Front 1), DP 1, OPS I/F | Video | HDMI 2(Rear 1, Front 1), DP 1, OPS I/F | ||||
USB | 2(For SoC, Rear/Front), 2 (for external 2.0 x1/3.0x1(Front)) | USB | 2(For SoC, Rear/Front), 2 (for external 2.0 x1/3.0x1(Front)) | ||||
Output | Output | ||||||
Video | HDMI 1 (Screen Share in Front) | Video | HDMI 1 (Screen Share in Front) | ||||
Audio | 1(Stereo Mini Jack) | Audio | 1(Stereo Mini Jack) | ||||
Touch Out | Touch Out 2 (USB Upstream Type, Front 1, Rear 1) | Touch Out | Touch Out 2 (USB Upstream Type, Front 1, Rear 1) | ||||
External Control | Touch Input / RS232C thru stereo jack, RJ45(For MDC) | External Control | Touch Input / RS232C thru stereo jack, RJ45(For MDC) | ||||
BT/WiFi | Yes (Keyboard/Mouse) | ||||||
Touch | Touch | ||||||
Type | IR | Type | IR | ||||
# of Drawing | 4 drawing (Internal) 20 drawing (External) | # of Drawing | 4 drawing (Internal) 20 touch (External) | ||||
Touch Pen Type | Passive Pen with magnet | Touch Pen Type | Passive Pen with magnet | ||||
Object Recognition Range | 2mm/ 4mm / 8mm / 50mm(Brush Mode : Dynamic Object Recognition) | Object Recognition Range | 2mm/ 4mm / 8mm / 50mm (Brush Mode : Dynamic Object Recognition) | ||||
Haze | 8%~12% | Haze | 8%~12% | ||||
Thickness | 3.2T | Thickness | 3.2T | ||||
Hardness | Heat Semi-Strengthened Glass | Hardness | Heat Semi-Strengthened Glass | ||||
Additional Film | AG, Hydrophobic Coated PET | Additional Film | AG, Hydrophobic Coated PET | ||||
Power | Power | ||||||
Type | Internal (Main 1ea, OPS 1ea) | Type | Internal (Main 1ea, OPS 1ea) | ||||
Power Supply | AC 100~240V 50/60Hz | Power Supply | AC 100~240V 50/60Hz | ||||
Power Consumption | Power Consumption | ||||||
Max[W/h] | 275 | Max[W/h] | 418 (OPS 19V/3.7A) | ||||
Stand-by (W) | 0.5 | Stand-by (W) | 0.5 | ||||
Typical[W/h] | 115 | Typical[W/h] | 151 | ||||
Rating[W/h] | 250 | Rating[W/h] | 380 (OPS 19V/3.7A) | ||||
BTU(Max) | 937.75 | BTU(Max) | 1,425.38 (OPS 19V/3.7A) | ||||
Mechanical Specification | Mechanical Specification | ||||||
Dimension (mm) | Dimension (mm) | ||||||
Set | 1721x1019.3x75.2 mm | Set | 1942.8x1144.1x69.4 mm | ||||
Package | 1905x1182x287 mm | Package | 2136x1311x260 mm | ||||
Weight (kg) | Weight (kg) | ||||||
Set | 58.3 kg | Set | 74.5 kg | ||||
Package | 71.7 kg | Package | 91.5 kg | ||||
Color | Charcoal Black | Color | Charcoal Black | ||||
VESA Mount (mm) | 400 * 400 | VESA Mount (mm) | 600 * 400 | ||||
Protection Glass | Yes | Protection Glass | Yes | ||||
Stand Type | Wall Mount | Stand Type | Wall Mount | ||||
Media Player Option Type | OPS Slot support | Media Player Option Type | OPS Slot support | ||||
Rotation | Landscape only | Rotation | Landscape only | ||||
Power Cable Length | 3M /2.4M(US) | Power Cable Length | 3M /2.4M(US) | ||||
Accessory | Power Cord, USB Upstream Cable(2ea), Pen(2ea, Black), OPS Box, Warranty/QSG | Accessory | Power Cord, USB Upstream Cable(2ea), Pen(2ea, Black), OPS Box, Warranty/QSG | ||||
Operation | Operation | ||||||
Operating Temperature | 0 ℃ ~ 40 ℃ | Humidity | 10 % ~ 80 % non-condensing | Operating Temperature | 0 ℃ ~ 40 ℃ | Humidity | 10 % ~ 80 % non-condensing |
Feature | Feature | ||||||
Key Features | Flip App | Key Features | Flip App | ||||
Orientation | Landscape | Orientation | Landscape | ||||
Remote Control | N/A | Remote Control | N/A | ||||
Special Features | H/W | Touch Overlay(IR), Front Connectivity, OPS I/F Support(w/OPS Box) Built in Speaker(10W x 2), WiFi/BT Module Embedded | Special Features | H/W | Touch Overlay(IR), Front Connectivity, OPS I/F Support(w/OPS Box) / Built in Speaker(10W x 2), WiFi/BT Module Embedded | ||
S/W | Flip S/W | S/W | Flip S/W | ||||
Platform | Muse-M (Tizen 6.0) | Platform | Muse-M (Tizen 6.0) | ||||
Internal Player | Processor | CA72 Quad(1.7GHz) 2MB L2 | Internal Player | Processor | CA72 Quad(1.7GHz) 2MB L2 | ||
On-Chip Cache Memory | L2 : 2MB | On-Chip Cache Memory | L2 : 2MB | ||||
Clock Speed | 1.7GHz CPU Quad | Clock Speed | 1.7GHz CPU Quad | ||||
Main Memory Interface | LPDDR4 1.6GHz 64bit 3.0GB | Main Memory Interface | LPDDR4 1.6GHz 64bit 3.0GB | ||||
Graphics | GPU : MaliG51 MP4@760MHz | Graphics | GPU : MaliG51 MP4@760MHz | ||||
Storage (FDM) | 16GB | Storage (FDM) | 16GB | ||||
Multimedia | N/A | Multimedia | N/A | ||||
IO Ports | USB 2.0 | IO Ports | USB 2.0 | ||||
Operating System | Tizen 6.0 : Samsung Proprietary OS(VDLinux) | Operating System | Tizen 6.0 : Samsung Proprietary OS(VDLinux) | ||||
Certification | Certification | ||||||
Safety | N/A | Safety | N/A | ||||
EMC | N/A | EMC | N/A | ||||
Security | 802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP | Security | 802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP | ||||
Accessory | Accessory | ||||||
Included | Power Cord, USB Upstream Cable(2ea), Pen(2ea, Black), OPS Box, Warranty/QSG | Included | Power Cord, USB Upstream Cable(1ea), Pen(2ea, Black), OPS Box, Warranty/QSG | ||||
Optional | Optional | ||||||
Stand | N/A | Stand | N/A | ||||
Mount | WMN6575SE | Mount | WMN8200SF | ||||
Specialty | Flip UX | Specialty | Flip UX | ||||
Media Player | Media Player | ||||||
Media Player | N/A | Media Player | N/A |
The WMA Flip 3 Series
