Monoprice 8678 SlimSelect Series Low Profile Full-Motion Articulating TV Wall Mount Bracket For LED TVs 23in to 42in, Max Weight 66 lbs., VESA Patterns Up to 200x200, Works with Concrete and Brick
8678-MONOPRICE
Description
The Monoprice full-motion TV mount supports adjustments in three dimensions; it can be swiveled ±50°, can be tilted ±15°, and can be rotated ±5°, allowing you to adjust it to the perfect angle.
This bracket is designed to mount an LCD, LED, or Plasma display with a VESA® mounting pattern of 100x100, 200x100, or 200x200, which includes most 23" to 42" TVs*. It can be mounted to any brick, masonry, or concrete type wall and can safely hold up to 66 lbs. (including the weight of the mount itself). Mounting hardware is included.
Specifications
| Model | 8678 |
| Type | Tilting/Swiveling |
| Minimum VESA® | 100 x 100 |
| Maximum VESA | 200 x 200 |
| Maximum Weight | 66 lbs. |
| Minimum Display Size* | 23" |
| Maximum Display Size* | 42" |
| Minimum Extension | 1.1" (27mm) |
| Maximum Extension | 10.3" (262mm) |
| Tilt Range | ±15 degrees |
| Swivel Range | ±50 degrees |
| Rotation Range | ±5 degrees |
| Construction | |
| Color | Black |
| Wall Plate Dimensions | 7.3" x 9.7" (185 x 247 mm) |
| Front Plate Dimensions | |
| Built‑in Level | No |
| Cable Management | No |
| UL® Certified | No |
| RoHS Compliant | Yes |
| Notes: | Brick/Concrete only, No logo on mount |
