Quick Specs
UM777H
Series
4K UHD
Resolution
50 "
Screen Size
Direct View LED
Display Technlogy
200 x 200
VESA
2 Year
Warranty
| CATEGORY | Category | Pro:Centric Smart | Pro:Centric Smart | Pro:Centric Smart | Pro:Centric Smart | ||||||||||||||||
| DISPLAY | Diagonal | 75" | 65" | 55" | 50" | ||||||||||||||||
| Resolution | 3,840 × 2,160 (4K Ultra HD) | 3,840 × 2,160 (4K Ultra HD) | 3,840 × 2,160 (4K Ultra HD) | 3,840 × 2,160 (4K Ultra HD) | |||||||||||||||||
| Brightness (Typ.) | 420 nits | 420 nits | 380 nits | 420 nits | |||||||||||||||||
| VIDEO | AI Picture Pro | Yes | Yes | Yes | Yes | ||||||||||||||||
| HDR 10 Pro / HDR HLG | Yes / Yes | Yes / Yes | Yes / Yes | Yes / Yes | |||||||||||||||||
| Game Optimizer | Yes | Yes | Yes | Yes | |||||||||||||||||
| AUDIO | Speaker (Audio Output) | 20 W | 20 W | 20 W | 20 W | ||||||||||||||||
| AI Sound | Yes | Yes | Yes | Yes | |||||||||||||||||
| AI Acoustic Tuning | Yes (Ready, MMR Required) | Yes (Ready, MMR Required) | Yes (Ready, MMR Required) | Yes (Ready, MMR Required) | |||||||||||||||||
| LG Sound Sync | Optical/Bluetooth wireless | Optical/Bluetooth wireless | Optical/Bluetooth wireless | Optical/Bluetooth wireless | |||||||||||||||||
| BROADCASTING SYSTEM | Digital | ATSC/Clear QAM | ATSC/Clear QAM | ATSC/Clear QAM | ATSC/Clear QAM | ||||||||||||||||
| Analog | NTSC | NTSC | NTSC | NTSC | |||||||||||||||||
| Global IPTV Support | Yes | Yes | Yes | Yes | |||||||||||||||||
| HOSPITALITY SOLUTION | Solution Type | Pro:Centric (Smart, Cloud, Direct, V), webRTC |
Pro:Centric (Smart, Cloud, Direct, V), webRTC |
Pro:Centric (Smart, Cloud, Direct, V), webRTC |
Pro:Centric (Smart, Cloud, Direct, V), webRTC |
||||||||||||||||
| Pro:Idiom (DRM / Media) | Yes / Yes | Yes / Yes | Yes / Yes | Yes / Yes | |||||||||||||||||
| SMART FUNCTION | webOS23, Web Browser, Magic Remote Compatibility (Ready), Multi View, Gallery Mode, Wi-Fi, Bluetooth, SoftAP, Screen Share, DIAL, Bluetooth Audio Playback, HDMI-eARC/ARC (HDMI 2), Voice Recognition (Standalone/Solution), IoT, Anti-theft System (Kensington Lock, Credenza / Security Aperture (55"/50": Need Stand), Lock Down Plate (55"/50": Need Stand) | ||||||||||||||||||||
| HOSPITALITY FEATURES | EzManager, USB Cloning, Wake on RF, WOL, Diagnostics (IP Remote), HTNG-CEC (1.4), Simplink (HDMI-CEC) (1.4), IR Out (RS-232C, MPI), Multi-code IR, Installer Menu, Welcome Screen (Splash Image), Insert Image, One Channel Map (LCM), Instant ON, VLAN ID, Mobile Remote, Port Block, Lock Mode (Limited), RJP (Remote Jack Pack) Compatibility (Teleadapt/Guestlink (HDMI-CEC), b-LAN, Energy Saving Mode, BEACON |
||||||||||||||||||||
| JACK INTERFACE | Side Access | Antenna/Cable In (Dual b-LAN), HDMI in x3 (2.0), USB In x2 (2.0), MPI Port (RJ12), RS-232C (3.5 mm TRRS), Speaker Out/Line Out (3.5 mm Stereo), Service Only (3.5 mm TRS) |
|||||||||||||||||||
| Bottom Access | Optical Digital Audio Out, TV-Link CFG (3.5 mm TRS) (b-LAN Service), LAN (RJ45), Aux LAN (RJ45) | ||||||||||||||||||||
| MECHANICAL | Stand Type | 1 pole (Fixed) | 1 pole (Fixed) | 1 pole (Swivel) | 1 pole (Swivel) | ||||||||||||||||
| Front Color | Dark Charcoal Gray | Dark Charcoal Gray | Dark Charcoal Gray | Dark Charcoal Gray | |||||||||||||||||
| VESA Compatible | 400 × 400 mm | 300 × 300 mm | 300 × 300 mm | 200 × 200 mm | |||||||||||||||||
| W × H × D (without Stand) |
66.0 x 37.8 x 1.2 in / 1,677 × 960 × 30.9 mm |
57.3 x 33.1 x 1.2 in / 1,456 × 840 × 29.7 mm |
48.7 x 28.2 x 1.2 in / 1,236 × 716 × 29.7 mm |
44.2 x 25.7 x 1.2 in / 1,123 × 652 × 29.7 mm |
|||||||||||||||||
| Weight (without Stand) | 73.4 lbs / 33.3 kg | 52.0 lbs / 23.6 kg | 33.1 lbs / 15.0 kg | 28.7 lbs / 13.0 kg | |||||||||||||||||
| W × H × D / Weight (with Stand) | 66.0 x 41.0 x 14.6 in / 1,677 x 1,042 x 370 mm |
57.3 x 35.8 x 11.2 in / 1,456 x 909 x 285 mm |
48.7 x 30.4 x 11.9 in / 1,236 × 771 × 303 mm |
44.2 x 27.9 x 11.9 in / 1,123 × 708 × 303 mm |
|||||||||||||||||
| Weight (with Stand) | 91.5 lbs / 41.5 kg | 60.4 lbs / 27.4 kg | 40.1 lbs / 18.2 kg | 35.7 lbs / 16.2 kg | |||||||||||||||||
| W × H × D / Weight (In Shipping) | 71.7 x 47.4 x 9.0 in / 1,820 × 1,205 × 228 mm |
63.0 x 38.2 x 8.0 in / 1,600 × 970 × 203 mm |
53.5 x 31.9 x 7.4 in / 1,360 × 810 × 187 mm |
47.8 x 29.7 x 7.4 in / 1,215 × 755 × 187 mm |
|||||||||||||||||
| Weight (In Shipping) | 115.5 lbs / 52.4 kg | 76.5 lbs / 34.7 kg | 47.6 lbs / 21.6 kg | 42.1 lbs/ 19.1 kg | |||||||||||||||||
| On Bezel Width (L/R/T/B) | 13.6 / 13.6 / 13.6 / 18.2 mm | 13.5 / 13.5 / 13.5 / 17.4 mm | 13.4 / 13.4 / 13.4 / 17.4 mm | 13.4 / 13.4 / 13.4 / 17.4 mm | |||||||||||||||||
| Off Bezel Width (L/R/T/B) | 7.6 / 7.6 / 7.6 / 14.8 mm | 7.5 / 7.5 / 7.5 / 14.8 mm | 7.5 / 7.5 / 7.5 / 14.8 mm | 8.4 / 8.4 / 8.4 / 15.2 mm | |||||||||||||||||
| ELECTRICAL | Power Supply (Voltage, Hz) | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | 100-240 Vac, 50/60 Hz | ||||||||||||||||
| Power Consumption (Max.) | 189 W | 144 W | 136 W | 119 W | |||||||||||||||||
| Power Consumption (Typ.) | 163 W | 128 W | 121.7 W | 101 W | |||||||||||||||||
| Standby Power Consumption | Under 0.5 W | Under 0.5 W | Under 0.5 W | Under 0.5 W | |||||||||||||||||
| WARRANTY & OTHER | Warranty | 2 Year Limited | 2 Year Limited | 2 Year Limited | 2 Year Limited | ||||||||||||||||
| Certifications | UL, FCC | UL, FCC | UL, FCC | UL, FCC | |||||||||||||||||
| UPC | 1 95174 06523 5 | 1 95174 06546 4 | 1 95174 06520 4 | 1 95174 06518 1 | |||||||||||||||||
| Accessories | Remote Type (S-Con / MMR (Optional)), Power Cable (1.8 m / Angle Type) | ||||||||||||||||||||
