Peerless XHB552 55″ Xtreme High Bright Outdoor Display, 2500 Nits, 24/7, 3 Year Warranty
Peerless XHB552 55″ Xtreme High Bright Outdoor Display, 2500 Nits, 24/7, 3 Year Warranty

Peerless XHB552 55″ Xtreme High Bright Outdoor Display, 2500 Nits, 24/7, 3 Year Warranty

XHB552-PEERLESS

XHB552 KEY FEATURES
  • Fully-Sealed All Weather Rated: IP68
  • Operating Temperature Range: -31°F – 140°F
  • Optically bonded, anti-reflective glass cover
  • Daylight readable with LED backlight and full HD 1080p resolution
  • Portrait and landscape installation
  • Offers 2500nits of light output

This product has been discontinued by the manufacturer, but we may have leftover stock in our warehouse. Request a stock check, below.

Use collapsible tabs for more detailed information that will help customers make a purchasing decision.

Ex: Shipping and return policies, size guides, and other common questions.

Model Specifications (Discontinued)

1080p FHD

Resolution

55"

Screen Size

Direct-Lit LED

Display Technlogy

2,500 nit

Brightness

3 Year

Warranty

24/7

Run Time

ACTIVE SCREEN SIZE 54.64″ (1388mm) OPERATING TEMPERATURE -31°F – 140°F (-35°C – 60°C)
PIXEL PITCH .210 x .630mm IP RATING IP68
ASPECT RATIO 16:9 SAFETY/EMC FCC Class A
RESOLUTION 1920 x 1080 AC INPUT 100 VAC to 240 VAC, 50 to 60 Hz
COLOR DEPTH 8Bit (16.7 Million Colors) POWER CONSUMPTION 293W
BRIGHTNESS 2,500cd/m2 ANALOG TV NTSC
BACKLIGHT ADJUSTMENT Automatic (Ambient Light Sensor) DIGITAL TV ATSC, MPEG4, QAM256, H.264
CONTRAST RATIO 1300:1 PICTURE ADJUSTMENT Brightness, Contrast, Tint,
Sharpness, Color
VIEWING ANGLE 178° Vertical/Horizontal PICTURE MODE Standard, Dynamic, Personal, Theater
RESPONSE TIME 8ms (Gray to Gray) COLOR TEMPERATURE
ADJUSTMENT Cool, Normal, Warm, Personal
REFRESH RATE 60Hz SCREEN ADJUSTMENT 4:3, 16:9, Full, Zoom, Point to Point
OPERATING TIME 24/7 CLOCK, SLEEP TIMER Yes
SIZE (W X H X D) 50.07″ x 29.23″ x 3.92″
(1272 x 742 x 100mm) V-CHIP Yes
COLOR Black DISPLAYPORT DP (x1)
GLASS IK10 Rated, Tempered & Anti-reflective ANALOG AUDIO OUTPUT 3.5mm Headphone Jack (x1)
VESA PATTERN 400 x 200, 400 x 400mm DIGITAL AUDIO OUTPUT Optical (x1)
NET WEIGHT 133lb (60kg) USB DATA INPUT USB 2.0 A (x1)
[Audio. Video, Text & Photo]
INPUT COMPARTMENT
(W X H X D) 12.06″ x 4.99″ x 2.21″
(306 x 126 x 56mm) RS232 DB-9 (Female)
TV INPUT Coax, 75 ohm (x1) 12VDC 2.5A OUTPUT 2.5mm (x1)
VGA INPUT 15 pin D-SUB (x1) USB POWER 5VDC 2.4A OUTPUT USB 2.0 A (x1)
HDMI INPUT HDMI (x3), 480i, 480p, 720p,
1080i , 1080p IR EXTENDER 3.5mm (x1)
CVBS INPUT 3.5mm (x1) AMBIENT LIGHT
SENSOR EXTENDER 3.5mm (x1)
YPBPR INPUT 3.5mm (x1) LAN INPUT RJ-45 (x1)
VGA STEREO AUDIO INPUT 3.5mm (x1) PACKAGE CONTENTS Display, Waterproof Universal Remote Control, User’s Guide, Hex Wrench, Power Cord, IR Extender
PACKAGE SIZE (W X H X D) 55.625″ x 34.125″ x 10.63″ (1413 x 867 x 270mm) PACKAGE SHIP WEIGHT 145lb (66kg)

The XHB552 Series

There has never been an outdoor daylight readable display built to withstand the harsh outdoor elements like the Peerless-AV XHB552 Xtreme High Bright. Featuring a fully sealed, IP68 Rated design and a patented Dynamic Thermal TransferTM System, Xtreme High Bright Outdoor Displays are maintenance-free, with no fans, vents or filters, and are fully protected against water, dust, moisture and even insects. The display’s cover glass is optically bonded, which increases the perceived contrast ratio and cuts down on glare, providing amazing picture quality even in direct sunlight. With an operating temperature range of -31°F to 140°F, XHB552 Xtreme Displays are designed to thrive year-round outside, without worry of extreme hot or cold temperature waves. This High Bright line of commercial displays offer 2500nits of light output to combat high ambient lighting conditions, while the ambient light sensor automatically adjusts the display’s brightness to optimize the power consumption and enhance the viewing experience. Providing unmatched capabilities, XHB552 Xtreme High Bright Outdoor Displays are the perfect digital signage or entertainment solution for any professional application.
