Model Specifications (Discontinued)
4K UHD
Resolution
75"
Screen Size
New Edge
Display Technlogy
500 nit
Brightness
3 Year
Warranty
24/7
Run Time
PANEL | |||
120Hz Slim Direct LED BLU | Screen Size (Inch) 43″, 49″, 55″, 65″, 75″, 85″, 98″ |
Resolution 3840 x 2160 (4K UHD) |
Pixel Pitch (mm) 75″ – 0.42975 x 0.42975 |
Active Display Area(mm) 75″ – 1650.24 (H) x 928.26 (V) |
Brightness(Typ.) 500 nit |
Contrast Ratio 75″ – 6000:1 |
Viewing Angle(H/V) 178/178 |
Display Colors 16.7M (True Display) 1.07B (Ditherd 10bit) |
Response Time(G-to-G) 8ms(Typ.) |
Display Colors Color Gamut 92% (DCI-P3, CIE 1976) |
Color Gamut 72% |
DISPLAY | |||
Dynamic C/R MEGA |
H-Scanning Frequency 30 ~ 81kHZ |
V-Scanning Frequency 48 ~ 75HZ |
Maximum Pixel Frequency 594MHz |
SOUND | |||
Speaker Type Built in Speaker(10W + 10W) |
|||
CONNECTIVITY – INPUT | |||
RGB DVI-D, Display Port 1.2 (1) |
Video HDMI 2.0 (2) |
HDCP HDCP2.2 |
Audio Stereo mini Jack, DVI, HDMI |
Output | |||
RGB HDMI 2.0 (Loop-out) |
Audio Stereo mini Jack |
External Control RS232C(in/out) thru stereo jack, RJ45 |
External Sensor IR |
POWER | |||
Type Internal |
Power Supply AC 100 – 240 V~ (+/- 10 %), 50/60 Hz |
Max[W/h] 110 |
Typical[W/h] 74 |
Rating[W/h] 100 |
BTU(Max) 375.1 |
Sleep mode 0.5 |
Off mode N/A |
MECHANICAL SPECS | |||
Dimension without stand (mm) 75″ – 1684.6 x 966.7 x 60.4 mm |
Package (WxHxD) 75″ – 1871 x 1131 x 234 mm |
Weight (kg) 75″ – 38 kg |
Package 75″ – 50.5 kg |
VESA Mount (mm) 75″ – 200 X 200 |
Stand Type Foot Stand (Optional) |
Bezel Width 16.2mm (Top, Side) / 19.3mm (Bottom) |
|
ENVIRONMENTAL CONDITIONS | |||
Operating Temperature 0℃~ 40℃ |
Humidity 10 % ~ 80 % |
Recommended Usage Hours 24/7 |
|
FEATURE | |||
Special Features: UHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0 |
Special Features Hardware: Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), Video Wall Daisy Chain(HDCP2.2:4EA,HDCP1.4:7EA), IP5x, Wi-Fi/BT Software: Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting) |
||
INTERNAL PLAYER | |||
Processor Cortex A72 1.7GHz Quad-Core CPU |
On-Chip Cache Memory L1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB |
Clock Speed 1.7GHz |
Main Memory Interface 2.5GB LPDDR4 1.5GHz 64bit |
Graphics Graphic resolution : 1920×1080 Output resolution : 3840×2160 (Scale up from graphic processing result.) |
Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available) |
Multimedia *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG |
IO Ports USB 2.0 |
Operating System Tizen 4.0 (VDLinux) |
The QM75N Series
