Model Specifications (Discontinued)
4K UHD
Resolution
42.5"
Screen Size
Direct-Lit LED
Display Technlogy
400 nit
Brightness
2 Year
Warranty
Run Time
| DISPLAY | |
| TYPE | Edge LED |
| RESOLUTION | 3,840 x 2,160 (4K UHD) |
| DIMENSIONS | Diagonal Size 42.5″ Bezel Width (L / R, U, B): on bezel based (mm) 10, 10, 15.2 Bezel Width (L / R, U, B): off bezel based (mm) 8.5, 8.5, 13.7 Vesa (mm) 200 x 200 WxHxD / weight (without stand) 38.3″ x 22.5″ x 2.8″ / 20.3lb WxHxD / weight (with stand) 38.3″ x 24.6″ x 8.6″ / 20.5lb WxHxD / weight (Carton) 41.7″ x 26.0″ x 8.6″ / 24.7lb |
| BROADCAST SYSTEM | |
| ANALOG | NTSC |
| DIGITAL | ATSC / VSB / Clear QAM |
| BRIGHTNESS | 400 |
| VIDEO | |
| PICTURE ENGINE | XD Engine |
| REAL CINEMA 24P (3:3 PULL DOWN) | Yes |
| ASPECT RATIO | 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan) |
| AUDIO | |
| AUDIO OUTPUT / SPEAKER SYSTEM | 10W + 10W / 2.0 ch |
| SOUND MODE | 6 modes (Standard, Cinema, Clear Voice, Sports, Music, Game) |
| FEATURES | |
| INSTALLATION | USB Cloning |
| MANAGEMENT | WOL, SNMP, Self Diagnostics via USB, Multi IR Code, HTNG/HDMI-CEC* |
| *HDMI-CEC : Compatibility can differ by equipment. | |
| HOSPITALITY | PDM (Public Display Mode), Lock Mode, Welcome Screen (Splash Image) / Video, Insert Image, External Speaker Out, RJP Compatibility, Crestron Connected® Certification, DPM (Display Power Management) mode, Time Scheduler |
| INTERFACE | |
| SIDE | HDMI In (2), USB 2.0 |
| REAR | RF In, AV In (Sharing with Component In), Component In + Video, Optical Digital Audio Out, HDMI In, RS-232C In, RJ45 (SNMP), External Speaker Out |
