Model Specifications (Discontinued)
1080p FHD
Resolution
48.7"
Screen Size
Direct-Lit LED
Display Technlogy
400 nit
Brightness
2 Year
Warranty
Run Time
DISPLAY | |
TYPE | Edge LED |
RESOLUTION | 3,840 x 2,160 (4K UHD) |
DIMENSIONS | Diagonal Size 48.7″ Bezel Width (L / R, U, B): on bezel based (mm) 8.8, 8.8, 13.8M Bezel Width (L / R, U, B): off bezel based (mm) 6.8, 6.8, 11.3 Vesa (mm) 300 x 300 WxHxD / weight (without stand) 43.6″ x 25.4″ x 2.8″ / 24.9lb WxHxD / weight (with stand) 43.6″ x 27.8″ x 9.2″ / 25.4lb WxHxD / weight (Carton) 47.0″ x 30.3″ x 6.2″ / 30.0lb |
BROADCAST SYSTEM | |
ANALOG | NTSC |
DIGITAL | ATSC / VSB / Clear QAM |
BRIGHTNESS | 400 |
VIDEO | |
PICTURE ENGINE | XD Engine |
REAL CINEMA 24P (3:3 PULL DOWN) | Yes |
ASPECT RATIO | 6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan) |
AUDIO | |
AUDIO OUTPUT / SPEAKER SYSTEM | 10W + 10W / 2.0 ch |
SOUND MODE | 6 modes (Standard, Cinema, Clear Voice, Sports, Music, Game) |
FEATURES | |
INSTALLATION | USB Cloning |
MANAGEMENT | WOL, SNMP, Self Diagnostics via USB, Multi IR Code, HTNG/HDMI-CEC* |
*HDMI-CEC : Compatibility can differ by equipment. | |
HOSPITALITY | PDM (Public Display Mode), Lock Mode, Welcome Screen (Splash Image) / Video, Insert Image, External Speaker Out, RJP Compatibility, Crestron Connected® Certification, DPM (Display Power Management) mode, Time Scheduler |
INTERFACE | |
SIDE | HDMI In (2), USB 2.0 |
REAR | RF In, AV In (Sharing with Component In), Component In + Video, Optical Digital Audio Out, HDMI In, RS-232C In, RJ45 (SNMP), External Speaker Out |
The UV340C Series
