Name: Samsung DM65E-BR 65″ E-Board Interactive Whiteboard, FHD, 380 Nits, 24/7, 3 Year Warranty
Brand: Samsung
SKU: DM65E-BR-SAMSUNG
Availability: OutOfStock

Samsung DM65E-BR 65″ E-Board Interactive Whiteboard, FHD, 380 Nits, 24/7, 3 Year Warranty

Key Features

Interactive whiteboard style design with a pre-assembled touch overlay from factory
Infrared touch screens that allows for dual drawing capabilities, enabling up to 10 touch points
All-in-one, PC-less E-board display solution with an embedded MagicIWB S2 software
Compatibility with an optional MagicIWB I2 software for advanced E-board functionality

65" 75" 82"

This product has been discontinued by the manufacturer, but we may have leftover stock in our warehouse. Request a stock check, below.

Use collapsible tabs for more detailed information that will help customers make a purchasing decision.

Ex: Shipping and return policies, size guides, and other common questions.

Model Specifications (Discontinued)

1080p FHD

Resolution

65"

Screen Size

120Hz Slim Direct LED BLU

Display Technlogy

380 nit

Brightness

3 Year

Warranty

24/7

Run Time

Series Name – DM65E-BR

SERIES NAME

DME-BR Series

Display – DM65E-BR

SCREEN SIZE

65″
PANEL TECHNOLOGY

120Hz D-LED BLU
RESOLUTION

1920×1080
ASPECT RATIO

16:9
BRIGHTNESS

380nit (with touch glass)
CONTRAST RATIO (TYPICAL)

4000:1
CONTRAST RATIO (DYNAMIC )

50,000:1
VIEWING ANGLE (H/V)

178:178
RESPONSE TIME

6ms

Connectivity – DM65E-BR

RGB – Analog D-SUB, DVI-D, Display Port 1.2, VIDEO – Rear: HDMI1, HDMI2, Front Tray Box: HDMI3 Component(CVBS Common), AUDIO – Stereo mini Jack, USB – Rear: USB 2.0 X 1, Touch in X 1, Front Tray Box: USB 2.0 X 2, Touch out (USB Upstream)
OUTPUT

AUDIO – Stereo mini Jack
EXTERNAL CONTROL

RS232C(in/out) thru stereo jack, RJ45
SENSOR

IR, Ambient Light

Power – DM65E-BR

POWER SUPPLY

AC 100 – 240 V~ (+/- 10 %), 50/60 Hz
POWER CONSUMPTION (TYPICAL/MAX)

200W/h / 264W/h
POWER CONSUMPTION (STANDBY)

<0.5W

Features – DM65E-BR

SPECIAL

H/W: Super Clear Coating, Temperature Sensor, Clock Battery(80hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded, Front Tray Box, S/W: Magic Clone(to USB), Auto Source Switching & Recovery, RS232C/RJ45 MDC,Plug and Play, PIP/PBP, Image Rotation, Button Lock, Built In MagicInfo Player S3, MagicIWB S2, Magic Presenter, USB Auto Switching, Firmware Update by Network, LFD New Home Screen, Predefined Template for Vertical Usage, Multi Channel, Mobile Control, Event Schedule, Backup Player
SMART SIGNAGE PLATFORM

Yes
BUILT-IN TUNER

Yes
24/7 OPERATION

Yes
BUILT-IN SPEAKERS

Built in Speaker(10W + 10W)
STORAGE

8GB

Dimensions – DM65E-BR

WITHOUT STAND (W X H X D)

60.4″ x 35.8″ x 3″
PACKAGING (W X H X D)

65.6″ x 40.9″ x 9.8″
BEZEL WIDTH

39.9mm

Weight – DM65E-BR

PRODUCT WEIGHT

101.6 lb.
PACKAGE WEIGHT

119.3 lb.

Included in Box – DM65E-BR

INCLUDED IN BOX

Quick Setup Guide, Regulayory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter, Pen 1, Pen Tray
OPTIONAL WALL MOUNT KIT

WMN4675MD, WMN4277SD, WMN6575SD
OPTIONAL STAND

STN-L7585F
OPTIONAL MEDIA PLAYER

Embbeded, SBB(Attachable), PIM(Attachable)

Mechancial Specs – DM65E-BR

VESA MOUNT

400x400mm

Operation – DM65E-BR

OPERATING TEMPERATURE

0℃~ 40℃
OPERATING HUMIDITY

10~80%

Download Specs PDF

The DM65E-BR Series

The DM65E-BR Samsung 65 inch LED TV for business is a ready-to-use, all-in-one E-Board display solution. The large 65″ display includes a pre-assembled touch overlay. The embedded System-on-Chip (SoC) media player and E-Board software makes it portable, flexible and easy to set up. And with a full range of connectivity options, including Wi-Fi® for seamless connection to mobile devices, you can meet your organization’s specific presentation needs.

Features

LARGE E-BOARD FOR CORPORATE AND EDUCATIONAL ORGANIZATIONS

This all-in-one E-Board display solution provides portability and flexibility while minimizing set-up time in meeting rooms or classrooms. The large 65″ screen on the DM65E-BR maximizes readability to facilitate smooth and informative presentations.

INCLUDED, PRE-ASSEMBLED TOUCH OVERLAY

The DM65E-BR comes with a pre-assembled touch overlay to transform your display into an interactive whiteboard with up to 10 simultaneous touchpoints and dual drawing capability. The factory assembly means it takes less time to install, so you can get right to creating more collaborative and dynamic presentations.

ALL-IN-ONE SOLUTION

Along with the display itself and included touch overlay, this E-Board solution features an embedded System-on-Chip (SoC) media player for a PC-less touch solution. Also included is an E-Board software application. With all of this right out of the box, you’ll enjoy portability, flexibility and a simple setup.

OPTIONAL SAMSUNG MAGICIWB I2 SOFTWARE

The optional MagicIWB I2 solution can transform a traditional presentation into a dynamic educational experience with on-screen note-taking functionality, video and image capture capability. So you can deliver rich content and interactivity in your meeting rooms or classrooms.

ENHANCED SYSTEM-ON-CHIP PERFORMANCE WITH A QUAD CORE CPU

Powered by a System-on-Chip (SoC) semiconductor and quad core CPU with 8GB of storage, Samsung’s SMART Signage Platform is an open and integrated player side media platform that provides a powerful, streamlined solution to reduce TCO for digital signage deployments, through savings in hardware, installation and operating costs.

FULL RANGE OF CONNECTIVITY OPTIONS INCLUDING WI-FI®

Versatile connectivity options include USB 2.0, HDMI, RJ45, RS232C, Wi-Fi® and more. With Wi-Fi®, enjoy seamless connectivity to mobile devices, for easy media sharing and screen control to simple content mirroring from a tablet or mobile phone to your display.
