Barco ClickShare CX-20 Wireless Conference System for Small Meeting Rooms and Huddle Spaces
Barco ClickShare CX-20 Wireless Conference System for Small Meeting Rooms and Huddle Spaces

Barco ClickShare CX-20 Wireless Conference System for Small Meeting Rooms and Huddle Spaces

CX-20-BARCO

The modern world of enterprise requires smooth collaboration and flexibility, especially when it comes to team meetings in huddle rooms, and this is exactly what Barco ClickShare CX-20 provides. Encouraging creative innovation through seamless wireless conferencing, ClickShare CX-20 wireless conference call speaker and microphone can make meetings more inspiring and more productive.

Start a huddle meeting from your device

With ClickShare CX-20, it’s easier than ever to start remote huddle meetings from your device, bringing a seamless and immersive conferencing experience to all participants, whether local, guest or remote. Use your preferred conferencing software combined with the ClickShare Conferencing Button and you can start your conference in less than seven seconds. The CX-20 connects wirelessly to existing huddle room cameras, speakerphones and audio peripherals, saving time and maximizing efficiency.

Decide how you want to collaborate

ClickShare CX-20 provides you with exceptional flexibility and choice, enabling you to decide just how you want to collaborate. Whether you’re on PC, Mac or mobile, the ClickShare Wireless Conferencing Button and ClickShare Collaboration App facilitate a user experience that’s both straightforward and consistent. In addition to its multi-device compatibility, ClickShare CX-20 is also fully compatible with your conferencing platform (UC) technology and your brand of USB-peripherals. Additional features such as local view of the room display help to optimize the experience.

Enhanced security and seamless integration

A perfect fit for any business environment, the ClickShare CX-20 wireless conferencing system comes equipped with a selection of great features for enhanced security and seamless integration. ClickShare Conference provides hassle-free integration with any IT network, while the XMS (Cloud) Management Platform provides for easy device management, as well as an intuitive user experience and clear analytics to get more out of your digital workspace.


Unlock Exclusive Savings!  Add multiple items to your cart and our reps will work with you to get the best possible price for your entire project. You can update quantities in the cart.
GENERAL SPECIFICATIONS
OPERATING SYSTEM Windows 8/8.1/10. macOS 10.13 and higher.
Android v9 and higher (ClickShare App)*
iOS 12 and higher (ClickShare App)*
OUTPUTS Video: 4K UHD (3840*2160) @ 30Hz. HDMI 1.4b
Audio: USB, HDMI
USB 1 X USB-A, 1 X USB-C
CLICKSHARE BUTTONS 1
CLICKSHARE APP Desktop & Mobile*
NATIVE PROTOCOLS Airplay, Google Cast*, Miracast*
NOISE LEVEL Max. 25dBA @ 0-30°C
Max. 30dBA @ 30-40°C
AUTHENTICATION PROTOCOL WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
WIRELESS TRANSMISSION PROTOCOL IEEE 802.11 a/g/n/ac and IEEE 802.15.1
REACH Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
Frequency band 2.4 GHZ and 5 GHz (DFS)
FREQUENCY BAND 2.4 GHZ and 5 GHz (DFS channels supported in select number of countries)
CONNECTIONS 1x Ethernet LAN 1Gbit
1x USB Type-C 2.0 (front); 1x USB Type A 2.0 (front)
TEMPERATURE RANGE Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
HUMIDITY Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
ANTI-THEFT SYSTEM Kensington lock
HUMIDITY Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
ANTI-THEFT SYSTEM Kensington lock
NETWORK CONNECTION LAN & WiFi *

* depends on configuration, available in future firmware updates

WARRANTY 1 year standard. 5 years coverage via SmartCare

The CX Series

For closer collaboration and an immersive conferencing experience, Barco CX ClickShare wireless conference solutions have just what your business needs. Connectivity is at the heart of modern business, and with wireless conferencing technology from ClickShare you can link up with colleagues in a matter of seconds.

Intuitive teamwork, hassle-free sharing and robust security are the hallmarks of ClickShare. With our wireless conference solutions, you can ‘bring your own meeting’ from anywhere and with any device, allowing you to link up with remote colleagues with the minimum of fuss.

Features

COLLABORATION VIA THE QUICK BUTTON

Access a set of collaborative features. Get a copy of the main screen on your laptop & easily view content in full detail. It also opens up a range of advanced functions.

TRIPLE AGNOSTIC

The Barco ClickShare conference system can be used on your laptop or desktop, connects instantly with your brand of peripherals and works with your conferencing platform (UC).

ISO 27001 CERTIFIED

As first wireless collaboration technology to obtain ISO 27001 Certification, we commit to the right processes and structures for the highest international security standards.

MANAGEMENT DASHBOARD

Managing ClickShare across your business is simple with our XMS (Cloud) Management Platform.

SMARTCARE

The Barco conference system includes five years of coverage and a license to the XMS insights module, as well as increased service levels.

NETWORK INTEGRATION

Whether you want to connect one unit to the network via ethernet or create a dedicated VLAN for all ClickShare units, you can integrate seamlessly within your network.
