Sharp PN-R606 professional 60″ LCD monitor for digital signage

Sharp PN-R606 professional 60″ LCD monitor for digital signage


  • 60″ Class (60″ diagonal) Screen Size
  • Brilliant High Definition (1920 x 1080) LCD Display
  • Intel® Mini-OPS Expansion Slot supports the optional PN-ZB03H HDBaseT™ 2.0 and PN-ZB03W Wireless Expansion Boards
  • Landscape, Portrait, Face-up, Face-down Operation
  • Built-in 10W per Channel Stereo Audio System
  • Engineered for 24/7 Commercial Use
  • 700 cd/m2 Brightness; 5,000:1 Contrast Ratio
  • Crestron Connected™ Compatibility

Model Specifications

1080p FHD



Screen Size

Direct View LCD

Display Technlogy


Run Time

700 nit


3 Year


INSTALLATION Landscape / Portrait / Face-up / Face-down
LCD PANEL 60″ Class widescreen (60″ diagonal) UV2 A*1 LCD
Max. Resolution 1,920 x 1,080 pixels
Max. Display Colours (approx.) 1.06 billion colors
Pixel Pitch 0.693 x 0.693 mm
Brightness*1 700 cd/m2
Contrast Ratio 5,000 : 1
Viewing Angles (H/V) 176°/176° (CR less than 10)
ACTIVE SCREEN AREA (W X H) 52 3/8″ X 29 7/16″
Response Time 8 ms (grey to grey, avg.)
Backlight LED, edge lit
Computer Input Video Analog RGB (0.7 Vp-p) [75 Ω], Digital (DVI 1.0 standard–compliant), DisplayPort 1.2, HDMI
Synchronisation Horizontal/vertical separation (TTL: positive/negative), Sync on green*3
, Composite sync (TTL: positive/negative)*3
Input Terminals DisplayPort x 1, DVI-D 24-pin (HDCP compatible) x 1, Mini D-sub 15-pin x 1, HDMI (PC/AV signal compatible) x 2, RS-232C x 1, 3.5 mm-diameter mini stereo jack x 1
Output Terminals DisplayPort x 1, 3.5 mm-diameter mini stereo jack x 1, RS-232C x 1
Power Supply 100 V – 240 V AC, 50/60 Hz
Power Consumption 190 W
Environmental Conditions 0°C to 40°C
Dimensions (W x D x H) (approx.)
(display only)
100 V – 240 V AC, 50/60 Hz
Accessories AC power cord, remote control unit, battery (AAA size x 2), CD-ROM, set-up manual, cable clamp x 2, ceiling mounting bracket x 8, ceiling mounting bracket fixing screw x 24, logo sticker

The PN-R606 Series

Inclined to Deliver Maximum Impact
When it comes to digital signage, size and flexibility matter. Sharp’s 60″ Class (60″ diagonal) PN-R606 professional LCD monitors offer high-impact screen space along with the flexibility to match your installation location. Whether set up at a tilted angle or hung from the ceiling, these eye-catching Sharp PN-R606 60″ LCD monitors have the size to convey your message clearly and vividly to your audience. DisplayPort™ 1.2 connectivity comes standard, and the interface can be expanded with an optional wireless board or HDBaseT™ 2.0 receiver board. All this flexibility gives you greater scope to create an appealing space and deliver a compelling message

Key Features

Excellent Image Quality
Whether in a landscape or portrait orientation, the Sharp PN-R606 60″ LCD monitors can be installed face up or tilted backward to an angle up to 90 degrees and forward to an angle up to 45 degrees. Such flexibility helps you to incorporate these monitors into a wider-than-ever variety of settings.

Adaptable to Various Settings
Whether in a landscape or portrait orientation, Sharp PN-R606 60″ LCD monitors can be installed face up, face down, or tilted forward or backward at an angle of up to 90 degrees. Such flexibility helps you to incorporate these monitors into a wider-than-ever variety of settings.

Stylish Design with Slim Bezel
Measuring just 8 mm on the top/right/left and 13 mm on the bottom, the PN-R606’s slim bezel helps onscreen content stand out and catch the viewer’s eye. Images †ll the screen beautifully, reaching almost to the edges of the monitor. The subtle design of this monitor makes it a stylish †t for virtually any location.

Hanging Installation
The Sharp PN-R606 60″ LCD monitors can be suspended by wire from their rear housing, using the bundled mounting brackets. Appearing to oat in mid-air, a wire-suspended PN-R606 creates a sophisticated impression that catches the eye.

Functional Remote Control
The PN-R606’s remote controller offers enhanced operability. For example, the remote controller and monitors can be assigned an identity number (from 0 to 9) for mutual recognition, which enables the remote to send commands to the targeted monitor only. The remote also lets you perform basic operations on connected HDMI™-CEC compatible devices, including power on/off. And it has three designated function buttons—HDMI, DisplayPort, and Option—to simplify input switching.

24/7 Operation
Built solid, Sharp PN-R606 60″ LCD monitors are ideal for use in demanding professional applications that require around-the-clock operation, seven days a week.


  1. Quality and Performance: Professional displays are typically built to higher standards with superior image quality and performance. They often feature advanced technologies like high color accuracy, wider color gamut, deeper black levels, and better image processing capabilities.
  2. Durability and Reliability: Professional displays are engineered to withstand continuous and demanding use in commercial environments. They are built with higher-quality components, have better heat management systems, and are designed to operate for extended hours without compromising performance or longevity.
  3. Connectivity and Customization: Professional displays often offer a wider range of input and output options to accommodate various professional devices and workflows. They may include specialized ports for connecting professional-grade cameras, video editing equipment, and other peripherals.
