Samsung QB13R 13″ QBR series, 4K UHD Smart Signage, 300 Nits, 16/7, 3 Year Warranty
Samsung QB13R 13″ QBR series, 4K UHD Smart Signage, 300 Nits, 16/7, 3 Year Warranty
Samsung QB13R 13″ QBR series, 4K UHD Smart Signage, 300 Nits, 16/7, 3 Year Warranty
Samsung QB13R 13″ QBR series, 4K UHD Smart Signage, 300 Nits, 16/7, 3 Year Warranty

Samsung QB13R 13″ QBR series, 4K UHD Smart Signage, 300 Nits, 16/7, 3 Year Warranty


  • Engage customers with lifelike images through ultra high-definition resolution
  • Deliver UHD-level picture quality even with lower resolution content through innovative UHD upscaling technology and unique picture-enhancing features
  • Dynamic Crystal Color allows viewers to enjoy a wider spectrum of colors, up to one billion shades
  • New symmetrical, slim design simplifies installation and complements any environment
  • Secure, PC-free operation through Knox and rigid three-layer protection

Unlock Exclusive Savings!  Add multiple items to your cart and our reps will work with you to get the best possible price for your entire project. You can update quantities in the cart.

Model Specifications




Screen Size


Display Technlogy


Run Time

300 nit


3 Year


Diagonal Size 13
Type Edge LED
Resolution 1920*1080 (Full HD)
Pixel Pitch(mm) 0.153 x 0.153
Active Display Area(mm) 293.76 (H) x 165.24 (V)
Brightness(Typ.) 300 nit
Contrast Ratio 800:1
Viewing Angle(H/V) 178/178
Response Time(G-to-G) 8ms(Typ.)
Display Colors 16.7 M (real 6bit, dither 8bit)
Color Gamut 45%
Operation Hour 16/7
Haze 10%
Dynamic C/R MEGA
H-Scanning Frequency 30 ~ 81kHZ
V-Scanning Frequency 48 ~ 75HZ
Maximum Pixel Frequency 594MHz
Speaker Type Built in Speaker(5W)
Video HDMI 1.4 (1)
USB USB 2.0 x 1
Audio Stereo Mini Jack
External Control RS232C(in) thru stereo jack, RJ45
Type Adapter
Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
Max[W/h] 27.5
Typical[W/h] 13
Rating[W/h] 25
BTU(Max) 93.8
Sleep mode 0.5
Mechanical Specification
Dimension (mm)
Set 322.0x193.5x28.2
Package 376x132x248
Weight (kg)
Set 0.9
Package 1.7
VESA Mount (mm) 100 X 100
Stand Type Bar Type Simple Stand (Inbox)
Bezel Width (mm) 12.2mm
Operating Temperature 0  ℃  ~   40   ℃ Humidity 10  %  ~   80   %
Key Features Small Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
Orientation N/A
Remote Control N/A
Special Features H/W : Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(5W 1ch), IP5x Rating, Wi-FiSW : Auto Source Switching & Recovery,LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player Processor Cortex A72 1.7GHz Quad-Core CPU
On-Chip Cache Memory L1 Instruction Cache : 48KBL1 Data Cache : 32KBL2 Cache : 2MB
Clock Speed 1.7GHz
Main Memory Interface 2.5GB LPDDR4 1.5GHz 64bitGraphic resolution : 1920x1080
Graphics Output resolution : 3840x2160 (Scale up from graphic processing result.)
Storage (FDM) 8GB (3.88GB Occupied by O/S, 4.12GB Available)
Multimedia *Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG
IO Ports USB 2.0
Operating System Tizen 4.0 (VDLinux)
Safety 60950-1
EMC Class B
Included Quick Setup Guide, Warranty Card,Power Cord, Remote Controller, Batteries, Bar Type Simple Stand
Stand Bar Type Simple Stand(inbox)
Mount -
Specialty N/A
Media Player
Media Player N/A

The QBR Series

Through intelligent UHD upscaling technology, Samsung’s QB43R performs edge restoration and noise reduction to deliver UHD picture quality even with lower resolution content. Backed by Tizen 4.0, the QB43R also provides reinforced capability with multiple web formats and secured protection. Additionally, its new slim design simplifies wall mounting and ensures seamless installation. Inquire about the QB43R Samsung 43 Inch Smart Signage TV today!

Key Features

Samsung’s superior visual display technology has positioned them as the industry leader in the digital signage market for a decade and in the TV market for 12 years. As an expert in picture quality in the display industry, Samsung is able to deliver best in-class picture quality through their new QBR series. The signage provides rich and flawless colors, sleek and durable design, powerful performance through Tizen 4.0 and secured protection. Samsung’s QB43R is also able to upscale even the lowest resolution content to UHD picture quality. For commercial displays, this technology advancement means highly visible signage with unmatched accuracy to help capture the attention of potential customers. It also means savings both in cost and time for businesses who can produce content more inexpensively at a lower resolution and still display it in stunning UHD quality.

Incredible 4K picture quality
Samsung’s new QB43R is able to capture customer attention by providing an incredibly clear picture, showcasing lifelike images and intricate details better than ever before thanks to ultra high-definition 4K resolution.

QB43R UHD Upscaling
Samsung’s global leadership in display technology and picture quality spans more than a decade. Thanks to superior semi-conductor technology, Samsung has developed the most powerful video processor available. Additionally, intelligent UHD upscaling technology is a cutting-edge solution based on Samsung’s proprietary intelligent UHD engine that allows content developed at a lower resolution to be elevated to UHD-level quality. It also performs edge restoration and noise reduction to optimize on-screen text and imagery with crisp edges and fine detail.

Dynamic Crystal Color
Dynamic Crystal Color is what brings the incredible, lifelike color to the QB43R Samsung 43 Inch Smart Signage TV. Using 10-bit processing, the displays are able to showcase a wider spectrum of colors — up to a billion different shades — capturing subtle differences for flawless color expression, critical to businesses in ensuring brand consistency across communication channels. The QBR series also features HDR10+ functionality that converts standard definition (SDR) content to HDR quality for sharper contrast and more vivid colors.

Slim and Symmetrical Design
The all-new slim and symmetrical design of the QB43R Samsung 43 Inch Smart Signage TV significantly simplifies wall mounting the display and ensures installation is a seamless process. The display’s power inlet direction has been redesigned to sit flush against the wall. The new design sets guarantees a long life cycle ensuring the QBR series will stand the test of time.

Powerful, all-in-one solution
The Samsung SMART Signage Platform (SSSP) is an open-source, all-in-one solution embedded in Samsung SMART signage that simplifies installation and maintenance. With SSSP, there is no need for any external devices to communicate with the server or play digital media enjoying easy development, reinforced capability with multiple web formats, and secured protection.


  1. Quality and Performance: Professional displays are typically built to higher standards with superior image quality and performance. They often feature advanced technologies like high color accuracy, wider color gamut, deeper black levels, and better image processing capabilities.
  2. Durability and Reliability: Professional displays are engineered to withstand continuous and demanding use in commercial environments. They are built with higher-quality components, have better heat management systems, and are designed to operate for extended hours without compromising performance or longevity.
  3. Connectivity and Customization: Professional displays often offer a wider range of input and output options to accommodate various professional devices and workflows. They may include specialized ports for connecting professional-grade cameras, video editing equipment, and other peripherals.
